商品の詳細:
お支払配送条件:
|
| Function: | Step-Up, Step-Down | Output Configuration: | Positive or Negative |
|---|---|---|---|
| Topology: | Buck, Boost | Output Type: | Adjustable |
| Number of Outputs: | 1 | ||
| ハイライト: | 600V/125A MOSFET IPA60R125P6,Automotive Grade MOSFET IPA60R125P6,IPA60R125P6 |
||
IPA60R125P6 600V/125A MOSFET 60mΩ RDS(on) TO-247 Package Fast Switching High Efficiency Automotive Grade Robust Thermal Performance - Ideal for Motor Drives & Inverters
Features
•IncreasedMOSFETdv/dtruggedness
•ExtremelylowlossesduetoverylowFOMRdson*QgandEoss
•Veryhighcommutationruggedness
•Easytouse/drive
•Pb-freeplating,Halogenfreemoldcompound
•Qualifiedfor industrialgradeapplicationsaccordingtoJEDEC(J-STD20 andJESD22)
Applications
PFCstages,hardswitchingPWMstagesandresonantswitchingstages fore.g.PCSilverbox,Adapter,LCD&PDPTV,Lighting,Server,Telecom andUPS.
Description
CoolMOS™isarevolutionarytechnologyforhighvoltagepower MOSFETs,designedaccordingtothesuperjunction(SJ)principleand pioneeredbyInfineonTechnologies.CoolMOS™P6seriescombinesthe experienceoftheleadingSJMOSFETsupplierwithhighclassinnovation. TheoffereddevicesprovideallbenefitsofafastswitchingSJMOSFET whilenotsacrificingeaseofuse.Extremelylowswitchingandconduction lossesmakeswitchingapplicationsevenmoreefficient,morecompact, lighterandcooler.
INFORMATION
|
Category
|
|
|
|
Mfr
|
|
|
|
Series
|
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Active
|
|
|
FET Type
|
|
|
|
Technology
|
|
|
|
Drain to Source Voltage (Vdss)
|
600 V
|
|
|
Current - Continuous Drain (Id) @ 25°C
|
|
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
10V
|
|
|
Rds On (Max) @ Id, Vgs
|
125mOhm @ 11.6A, 10V
|
|
|
Vgs(th) (Max) @ Id
|
4.5V @ 960µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs
|
56 nC @ 10 V
|
|
|
Vgs (Max)
|
±20V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
2660 pF @ 100 V
|
|
|
FET Feature
|
-
|
|
|
Power Dissipation (Max)
|
34W (Tc)
|
|
|
Operating Temperature
|
-55°C ~ 150°C (TJ)
|
|
|
Grade
|
-
|
|
|
Qualification
|
-
|
|
|
Mounting Type
|
Through Hole
|
|
|
Supplier Device Package
|
PG-TO220-FP
|
|
|
Package / Case
|
|
|
|
Base Product Number
|
Drawing
