SL02-GS08 80V Phototransistor Optocoupler 50mA Collector Current High CTR 4-Pin SOP 5000% VISO -55°C to +110°C Halogen-Free Signal Isolation Solution
The SL02-GS08 is a high-reliability phototransistor optocoupler designed to provide electrical isolation between two circuits. It features a high isolation voltage of 5000 Vrms, making it a safe and robust solution for protecting sensitive control components from high-voltage noise and transients.
Housed in a compact 4-pin SOP (Small Outline Package), this optocoupler combines a high Current Transfer Ratio (CTR) with a wide operating temperature range of -55°C to +110°C. It is constructed with halogen-free materials and is compliant with international safety and environmental standards, ensuring suitability for demanding applications.
FEATURES
- For surface mounted applications
- Ideal for automated placement
- Low power loss, high efficiency
- Oxide planar chip junction
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
- Meets JESD 201 class 2 whisker test
- Wave and reflow solderable
- AEC-Q101 qualified
- Compatible to SOD-123W package case outline or SOD-123F and SOD-123FL
APPLICATIONS
- Switch Mode Power Supplies (SMPS): Provides feedback isolation.
- Industrial Control Systems: Isulates PLC I/O, sensors, and logic interfaces.
- Microcontroller Interface: Protects low-voltage MCUs from noisy power sections.
- Appliance Control: Used in air conditioners, washing machines, and other home appliances for safe control.
- Telecommunications Equipment: Provides signal isolation in network and communication devices.
